Description
- High efficiency solar cells
- Low iron tempered glass with anti-reflection coating and high transmission rate.
- Aluminum frame: Easy to install.
- Superior Multi-function junction box with water proof capabilities.
- Long lifespan
- Weather proof
- Resistant to moisture and etching. Not affected by geology.
| Model | SFSMBBB100W |
| Maximum Power (Pm) | 100W |
| Open Circuit Voltage (V) | 22.6V |
| Short-Circuit Current (Isc) | 5.75A |
| Maximum Power Current (Vmp) | 18.4V |
| Power Tolerance | 5.43A |
| Maximum System Voltage | 0~+3% |
| Module Application | DC1000V |
| Nominal Operating Temperature | 45±2◦C |
| Operating Temperature | -40◦C~ +85◦C |
| Dimension (mm) | 1010*670*35 |
| Cell Technology | MONO – Si |
