Pylontech 5.12 kWh – 51.2 V 100 Ah Lithium Battery (5 kW Class)

General

• Battery Type: Lithium Iron Phosphate (LiFePO₄)

• Nominal Voltage: 51.2 V

• Capacity: 100 Ah

• Energy: 5.12 kWh

• Usable Energy: ~4.6 kWh (90% DoD)

• Cycle Life: ≥6000 cycles @ 80% DoD

• Depth of Discharge: Up to 90%

• Protection: Integrated BMS (OVP, UVP, OCP, SCP, temp, balancing)

• Efficiency: ≥95%

Electrical

• Max Continuous Discharge Current: ~100 A

• Max Charge Current: ~100 A

• Parallel Connection: Supported (scalable systems)

Physical

• Cooling: Natural convection

• Operating Temp.: –10 °C to +50 °C

• Mounting: Rack / Wall

• Communication: CAN / RS485

• Warranty: Typically 5–10 years (model & reseller dependent)
