Features
- Rated Capacity: 200Ah
- Nominal Voltage: 51.2V
- Discharge Voltage Cut-off: 44.0V
- Equalized Charge Voltage: 58.4V
- Max. Continuous Charging Current: 200A
- Max. Continuous Discharging Current: 200A
- C Rating: 1.0C
- Weight Approx.: 44Kg
- Display: NO LCD
- Parallel/Series: Parallel connection up to 15 packs with full communications
- Dimensions (W*D*H) mm: 482*480*133mm
- Ports: 1x Positive Socket, 1x Negative Socket, 1xPower switch
- Cells New: Li-ion Prismatic cells
- Warranty: 1 Year
- Design Life: +/-10Years
- Cycle Life@1C: +/- 4000 Cycles @ 100% DOD, above 6000 cycles @ 80% DOD
- Certification: CE, UN38.3, IEC, MSDS
- Outer Package Material: Black sheet metal steel case
- Operating Temperature: Discharging: -10to+50°C Storage: -10to+50°C Charging:0 to+50°C
- Protection: Electronic Circuit Breaker, BMS Voltage Protection, Current Limiting
