Input / Output
Rated Power: 22KW
Rated Voltage : 400Vac+_10%
Rated Frequency: 50/60Hz
Current Range: 6-32A
Charging Interface Type: Type 2/5m
Spec of Incoming cables: 5*6mm
Basic Features
Way of Starting: Plug & Charge/Bluetooth/Remote/Schedule/App(RFID Optional)
Noise: 0dB
Operating Temperature: -30degrees - 50 degrees
Storage Temperature: -40degress - 70 degrees
Operating Humidity: 5% - 95%RH
Operating Altitude: Below 200m
IP Degree: IP54
Dimension (W*H*D): 170*400*110
Weight: 5.1KG
Way of Installation: Wall Mount
Energy Management: Support
Standby Power Consumption:<10W
Other Features
Status Indication: 3 Color LED
Firmware Update: Local/AOT
Way Of Communication: Bluetooth/Wi-Fi/Ethernet/4G (Optional)
Emergency Stop Protection: Support
Save Charging Record When Power Off: Support
Electricity Measurement: Support
External Communication: RS485/CAN
Communication Protocol: OCPP1.6
