CHARACTERISTICS
- Pump Size: 4 inch
- Outlet Size: 1.25 inch
- Power: 1500W (0.5 HP)
- Rated Voltage: 110 VDC (42 ~ 168 VDC)
- Max. Flow: 4,800 L/HR
- Max. Head: 203 M
- Motor: Permanent Magnet Brushless DC Motor Food
- grade oil-filled
- Outlet: 304 Stainless Steel
- Pump Body: 304 Stainless Steel
- Impeller: 304 Stainless Steel
- Motor Body: 304 Stainless Steel
- Screw: 304 Stainless Steel
- Shaft: 304 Stainless Steel
- Winding: Copper wire
- Enclosure: Die-cast Aluminium
- IP Grade: IP54
- Control Mode: 32 Bit/MCU/FOC/Sine Wave Current / MPPT
- Cooling Mode: Heat Dissipation By Fan
